2020-2024 Explorer ST 3.0L XTREME-DI GDI HIGH FLOW PUMP HPFP-EVO E049-30 (Store Display)

Original price was: $1,599.00.Current price is: $1,199.00.

-

This GDI high pressure pump was developed to replace the Bosch OEM high pressure pump. It delivers up to 25/45% more fuel flow when mounted on the same CAM-Lobe.
Maximum Fuel Pressure :

250bar / 3600psi (XDI-EVO)
260bar / 3800psi (XDI-HPFP60)
The kit comes with everything you need: the HPFP, base plate, hardware and an electric pigtail.

Our Injectors are actual +25% flow over stock Explorer ST Injectors.
These +25% are actual injector flow capacity without any software patches.

Customer-specific fittings and lines on request.

no meth, no PFI, no extra ECUs, no wiring, full control, full OBD Diagnostics.

In stock

The 5 Star Tuning Guarantee

  • Check Mark Satisfaction Guaranteed
  • Check Mark No Hassle Refunds
  • Check Mark Secure Payments
GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: XDIE049-30-SD Categories: , , , Tag:
HPFP Information
Maximum Rail Pressure
OEM = 200bar / 2900psi
XDI-EVO = 250bar / 3600psi
XDI-60 = 260bar / 3800psi
Fuel Compatibility: all known fuels, all Ethanol blendsElectric Connector: Bosch Compact 2-pinDriver Profile: XDI, you need to work with one of our authorized tuners, no support for self tunersAccessories: electric pigtail

MECHANICAL DATA

Geometric Volume
OEM 1.27cc / rev
XDI-EVO = 1.56cc/rev = +25% capacity
XDI-60 = 1.87cc/rev = +45% capacity
Maximum Flow Rate:
tbcHousing material: stainless steel, hard coated AluminumTuning Support:  HPTDry Weight: 1112 g

Injector Information

Our 100% XDI built and tested DI-Injectors are designed for the 2020+ Explorer ST. These injectors supply the required fuel flow for high horsepower applications without the need for auxiliary fuel systems.
Every Injector gets tested at 100bar and 200bar on OEM testing equipment at XDI. Every set gets flow matched to within ±1% at 100bar and 200bar fuel pressure !!!

25% greaterflow over stock

OEM Spray Pattern

OEM Idle Characteristics

No meth, no PFI, no extra ECUs, no wiring, full control, full On Board Diagnostics. Just raw power through proper fueling.

Weight 4 lbs
Dimensions 7 × 7 × 6 in
